AC Combine Harvester

ENGINE

TYPE :

No. of Cylinders :

6(SIX)

Cooling System :

Water Cooled

         CUTTER BAR

Width :

4199 mm

Height Adjustment :

Hydraulically

Cutting Height Min :

100 mm

Cutting Height Max :

700 mm

          REEL

TYPE :

Pick Up

Speed Adjustment :

Mechanically

Height Adjustment :

Hydraulically

       Thresher Drum

Dia of Drum :

600 mm

Length of Drum :

1270 mm

Speed of Drum :

535 to 1210 rpm

Adjustment :

Mechanically

No. of Rasp Bars :

8(Eight)

No. of Spikes :

128

Concave

Clearance Between :

16 to 39 mm

Concave & Thresher :

3 to 16 mm

No. of Spikes :

• Mechanically
• 36

Straw Walkers

No. of Straw Walkers :

5(FIVE)

Total Area :

46565 sq. cm.

     Cleaning

Area :

16422 sq. cm.

Adjustment :

Mechanically

          Ground Speed

1st Gear Km/h :

1.5 to 3.5

2nd Gear Km/h :

3.5 to 9.0

3rd Gear Km/h :

8.5 to 21.9

Reverse Gear Km/h :

3.5 to 9.0

         Fan

No. of Blades :

5(FIVE)

Diameter of Fan :

600 mm

Width of Fan :

1260 mm

Adjustment :

Mechanically

     Steering

Steering System :

Hydraulic

       Capacity

Fuel tank :

380 Lts.

Grain Tank :

2.64 meter Cube

Hyd. Oil Tank :

25 Lts.

Tyre Size

Front :

18.4/15/30

Rear/Trolley :

9.00 X 16

Dimensions

Length :

8535 mm

Height :

4572 mm

Min Ground Clearance :

460 mm

Weight :

9150 Kgs. (Approx.)

Working Capacity

Wheat :

4.5 Acres/hour approx.

Paddy :

4 Acres/hour approx.
